RCF HD12-A MK4
- 1400 watt 2-way peak power
- 130 dB max SPL
- Digital bi-amplification, SMPS
- DSP sound processing
- 90 degrees x 60 degrees, wide dispersion constant directivity horn
- 12" woofer, high power, 2.5" voice coil
- 1.0" HF driver, titanium dome, neodymium 1.5" voice coil
- FiRPHASE processing
- Frequency Response: 45 Hz / 20000 Hz
- Max SPL @ 1m: 130 dB
- Horizontal coverage angle: 90 degrees
- Vertical coverage angle: 60 degrees
- Compression Driver: 1.0", 1.5" v.c
- Woofer: 12", 2.5" v.c
- Input signal: bal/unbal
- Input connectors: XRL, Jack
- Output connectors: XLR
- Input sensitivity: -2 dBu / +4 dBu
- Mic. Input Sensitivity: -32 dBu
- Crossover frequencies: 1800 Hz
- Protections: Thermal, RMS
- Limiter: Soft Limiter
- Controls: Volume, Boost, Mic/Line
- Total Power: 1400 W Peak, 700 W RMS
- High frequencies: 400 W Peak, 200 W RMS
- Low frequencies: 1000 W Peak, 500 W RMS
- Cooling: Convection
- Connections: VDE
- CE marking: Yes
- Cabinet/Case Material: PP Composite
- Hardware: 1 x M10 top, 1 x M10 bottom, 3 x M6 bottom
- Handles: 1 Top, 2 Side
- Pole mount/Cap: Yes
- Grille: Steel
- Colour: Black
- Height: 647 mm / 25.47 inches
- Width: 380 mm / 14.96 inches
- Depth: 380 mm / 14.96 inches
- Weight: 18.3 kg / 40.34 lbs
Here we have the RCF HD12-A MK4 speaker for gigging professionals who want something that can give them incredible audio while being sturdy enough for life on the road. RCF have taken their years of expertise and added to it using an advanced FiR filtering technology to design this powerful speaker which houses high-quality drivers and a Class D amplifier with a solid aluminium structure that both stabilises the amplifier during transit and helps the fan-less heat dissipation. Meanwhile the unit itself has been built in such a way that it can be used both as a standard PA speaker as well as a stage monitor, making it a worthy investment and an excellent companion to your set up.
RCF cares about your sound. The new D-Line MK4 speakers boosts the performance with a series of brand new transducers, improves the sound quality with the revolutionary FiRPHASE processing and renew the grille design to exalt the professional look. The vocals are natural, the sound is clear at long distances, the SPL power is stable at very high levels. The concept of the HD-Line derives from the touring industry, bringing in an elegant and compact cabinet all the experience of RCF professional sound with the maximum reliability and strength for the intensive use on the road.
Connect your microphone, your device or your mixer to the speaker and turn up the volume: real plug&play. Perfect as a main front of house in small PA systems, high powered floor monitoring and unobtrusive fixed installation.
New Perspective on Linearity
RCF speakers are designed using a proprietary and advanced FiR filtering technology, conceived to deliver transparent sound, absolute clarity and perfect stereo images to the listener. The special FiRPHASE filters allow to achieve coherent distribution of sound for all listeners without phase distortions, ensuring minimum latencies to the system.
Woofers and compression drivers are precision built taking advantage of RCF's technologies and a wealth of professional knowledge and experience dedicated to achieving extremely high standards.
Powerful Class D Amplifiers
RCF's Class-D power amplifier technology packs huge performance operating with high efficiency into a lightweight solution. D-Line amplifiers deliver ultra-fast attack, realistic transient response and impressive audio performance. The amplifier features a solid mechanical aluminium structure which not only stabilises the amplifier during transportation but also helps the fan-less heat dissipation. All the D Line amplifiers present SMPS power supply section in order to produce maximum output and minimum transportation weight.
New Cabinet Shape
Every D LINE model can be used in the standard or stage monitor configuration
D LINE cabinets are moulded on a special polypropylene composite material designed to dampen down vibrations even at maximum volume settings. From moulding to the final texture, D-LINE offers the maximum reliability and strength for the intensive use on the road. The reflex port has been resized to offer a better efficiency. The HD 32-A is equipped with a top handle and a side handle with rubber handgrip for greater portability. The RCF HD 12-A features 3 ergonomically designed forged handles with rubber handgrip, 2 on the sides and one at the top. The HD 10-A is equipped with a top handle and a side handle with rubber handgrip for greater portability. At the bottom a rugged steel pole mount has been installed in all models. The new cabinet shape will allow every D-LINE model to be used in the standard configuration as well as in stage monitor model. Two M10 and 3 M6 threaded inserts are provided for optional mounting hardware in Installed Sound Applications.
