Alto TS308 Features and Specifications
Features:
- 2000 W peak (1300 LF + 700 HF) 1000 W continuous RMS (650 LF + 350 HF)
- 8-inch (203 mm) LF driver, 2.5-inch (65 mm) high-temperature voice coil
- 1.4-inch (35 mm) voice coil, neodymium magnet HF driver, with precision wave guide
- High quality, lightweight, cabinet design for easy transport, set up and installation
- Pole-mountable, wedge monitor, bracket installation or flown application with integral
- M6 suspension points
- Integrated 2-channel mixer with dual XLR 1/4-inch combo mic/line inputs, independent level controls, XLR Link output, Contour EQ switch and Ground-Lift switch
- Custom engineered high-efficiency class D amplifiers with passive cooling design No fan means the speaker runs cleaner, quieter and has greater long-term reliability
- Design Origin: Designed and tuned in the USA
Specifications:
- Output Power: 2000 W peak (1300 LF + 700 HF) 1000 W continuous RMS (650 LF + 350 HF)
- LF Driver: 8-inch (203 mm) LF driver, 2.5-inch (65 mm) high-temperature voice coil
- HF Driver: 1.4-inch (35 mm) neodymium magnet HF driver with precision waveguide
- Crossover: 2.5 kHz
- Maximum SPL: 129 dB peak, 126 dB continuous (dB SPL @ 1 m)
- Frequency Response: 62 Hz20 kHz (+ 3 dB)
- Frequency Range: 52 Hz22 kHz (-10 dB)
- Horn Coverage: 90° H x 60° V nominal
- Equalization: Contour Switch Low and High Frequency +3dB Boost
- Connectors: (2) XLR/TRS ¼ (6.35 mm) combo inputs, (1) XLR link output, (1) IEC power cable input
- Controls: (2) Volume, Power on/off switch, Contour switch, Ground-Lift switch
- Indicators: 2 x Power LED (front and rear), Clip limiter LED
- Protection: Electronic clip, Thermal and transducer overdrive protection
- Power Connection: IEC with Mains Fuse
- AC Voltage Input: 100,110120,220240 V, 50/60 Hz
- Enclosure: Trapezoidal, injection-molded, polypropylene enclosure, with perforated steel grille
- Mounting/Installation: 36 mm standard pole mount, Wall or celling mount using TSB810 bracket, Flown application with integral M6 suspension points, Wedge monitor
- Dimensions (HxWxD): 17.1 x 10.1 x 9.6 / 434mm x 256mm x 245mm
- Net Weight: 20.2 lbs. / 9.2 kg.
Alto TS312S Features and Specifications
Features:
- Driver: 12-inch with high-temperature, long-throw voice coil
- Amplifier: 1000W continuous, 2000W peak Class D power
- XLR outputs, with six discreet output modes for ideal matching with companion speaker
- Extended LF switch for increased EQ control
- Electronic clip, thermal and transducer overdrive protection
- Integrated 35mm pole socket
- Rugged, mar-resistant splatter-spray finish always looks good, even with heavy use
- Designed and tuned in the USA
Specifications:
- Output Power: 2000W peak, 1000W continuous
- Transducer Low: 12" (305mm) woofer
- Frequency Response: 44Hz 95Hz (- 3dB)
- Frequency Range: 38Hz 110Hz (-10dB)
- Maximum SPL: 129dB (@ 1m)
- Connections: (2) XLR+1/4" (6.35mm) inputs; (2) XLR outputs; (1) IEC power cable input
- External Controls:
- Volume control
- Signal/clip limiter with LED
- DSP output mode switch with LED
- Polarity-reverse switch with LED
- Extended low-frequency switch with LED
- Power switch with LED - Electronic Protections: Electronic clip, thermal and transducer overdrive protection
- Enclosure: Internally braced MDF cabinet; 36mm mounting pole socket on top panel
- Power:
- Connection: Standard IEC cable
- Input Voltage: 110120, 220240VAC; 50/60Hz
- Consumption: 1000W
- Fuse: T10AL AC250V (110120V) or T5AL AC250V (220240V) - Dimensions (H x W x D): 17.9 x 18.1 x 19.9" / 456 x 459 x 505mm
- Weight: 55.12 lbs. / 25kg
Gorilla Speaker Tripod Stands Features and Specifications
Features:
- Pair of speaker stands with bag
- Strong and reliable steel construction
- Suitable for most active and passive PA speakers and has standard 35mm poles
- Black powder-coated finish
- Quick-and-simple construction
- No loose parts
- Superb quality and value
Specification:
- Height: 100cm - 160cm
- Load Capacity: 45Kgs
- Material: Steel
- Finish: Black powder-coating
- Includes: 2 x stands, 1 x bag
This is a fantastic value package deal for a pair of Alto TS308 PA speakers which come with the Alto TS312S subwoofer, professional speaker stands and three XLR cables. This brilliant bundle has everything you could need for a powerful and impressive audio set up and comes with:
- 2x Alto TS308
- 1x Alto TS312S
- 2x Gorilla Tripod Speaker Stands
- 1x Speaker Stand Carry Bag
- 3x 6m XLR Cables
Alto TS308
The active powered Alto TS308 brings across everything you loved about the TS2 PA speaker series and improves on it. The Alto TS308 comes with an 8" woofer that despite its size can deliver a high quality and impressive audio performance. This speaker can be used in a variety of ways as it is stand mountable, can be used as a wedge monitor and with its M6 points is also flyable.
The all-new Alto Professional TS3 Series of professional loudspeakers deliver solutions for every performance and installation challenge. With 2000 watts of explosive bi-amplified power and newly-designed transducers, these speaker systems deliver truly high-performance audio, without compromise or restriction. Their elegant industrial design, lightweight but rugged construction, versatile mounting/placement application and intuitive user interface achieves a level of excellence and refinement that exceeds expectations.
Alto TS312S
Introducing the Alto TS312S Subwoofer; part of Alto's new TS3 range of subwoofers. Designed to complement their TS3 full-line speakers the Alto TS312S Subwoofer features a solid 12" woofer mounted in a computer-optimised, braced ported enclosure made from a dense wood composite. By itself the TS312S will deliver powerful bass with minimal distortion but as part of a full-range speaker set up will fill-out your sound and take all of the pressure of reproducing low bass frequencies without over working your other speakers.
Add a Rock-Solid Foundation to Your Music
There are times when your sound system needs additional low-frequency output and "punch". For those situations, Alto Professional proudly offers the TS312 powered subwoofer. This subwoofer extends the bass response of virtually any fullrange speaker, relieving that speaker of the difficult task of having to reproduce the low bass frequencies. The result? A system with stunning wide-range response characterised by dramatic, impactful low frequencies and effortless, undistorted mids and highs. The listening audience will hear everything with perfect clarity, from the lowest bass synth tones to the highest percussion bells and everything in between.
Premium Components
TS312S features a rugged, long-excursion woofer mounted in a solidly-braced ported enclosure, computer-optimised for powerful low-frequency performance. The enclosure itself is made from a dense wood composite. This strong, resonant-free material has virtually perfect acoustic characteristics, which ensures that the subwoofers' output is always clear and impactful. Conventional enclosures with flex-prone thin metal or plastic walls actually rob the speaker of acoustic impact by dissipating the driver's energy as cabinet vibration. A sturdy, braced wood composite enclosure doesn't waste the driver's motion as cabinet resonance.
The Perfect Match
Strong, clear output is only half the battle, however in order for a subwoofer to be part of an ideal speaker system, it has to blend seamlessly with the companion speaker. This is where the Alto Professional's TS312S truly excels. All TS300-series subwoofers have a choice of six selectable DSP output modes, so the subwoofer's frequency response and crossover frequency are perfectly-matched to the speaker it's being used with. Four of these six output options match the subwoofer perfectly with Alto TS2 and TS3 full-range speakers, while the other two output options (Hi-Pass or Bypass mode) ensure a perfect match even with non-Alto full-range speakers.
Precision-Engineered for Performance
Our computer design techniques feature advancements such as Finite Element Analysis (FEA), which enables us to optimise the speaker's magnetic structure and maintain a tight voice coil gap for maximum sensitivity. Our voice coils themselves have extremely tight windings that ensure maximum utilisation of the input signal and our adhesives exhibit unrivalled consistency and durability under high temperature conditions for unsurpassed system reliability. TS312S features an onboard 2000-watt amplifier (1000 watts continuous) with proprietary limiting circuitry that provides electronic clip, thermal and transducer overload protection, ensuring that the system always sounds clean and clear, no matter how hard it's pushed.
Gorilla Speaker Tripod Stands
Here we have the best selling Gorilla GSS-Kit high-quality PA speaker tripod stand package that includes a LIFETIME WARRANTY. This complete PA stand kit comprises of a pair of compact tripod PA speaker stands and a high-quality carry bag and is perfect for mobile DJs, bands and other live performers who take their show on the road.
Unlike much cheaper kits, the GSS-Kit comes equipped with heavy-duty steel speaker stands. With more and more performers using active (powered) speakers, which have onboard amplification and are much heavier than their passive counterparts, it is important to choose speaker stands that can handle the extra weight without buckling or becoming unstable. The speaker stands in the GSS-KIT each have a maximum loading of 50KG which makes them ideal for more heavy-duty applications.
Each speaker stand is fully height-adjustable from 100-160cm meaning they can be tailored to the venue you are playing. These stands are quick and easy to set-up/break-down and fully-integrated toughened plastic fittings mean that there are no loose parts that can easily get forgotten or lost in transit from gig-to gig. A safety locking pin is used in each stand to add additional strength and security to the stand and provide peace-of-mind for the performer.
This pair of stands is supplied with a high-quality carry bag which makes the speakers easier to carry from gig-to-gig and also helps to protect the stands from knocks and scuffs when on-the-road or in storage.
